API Plan 76 is a piping arrangement for collecting and managing leakage from mechanical seals, specifically designed for situations where the leakage from the inner seal is a gas or vapor.Its used in non-condensing applications, often with a dry running containment seal.The main purpose of Plan 76 isto prevent direct leakage of the pumped fluid to the atmosphere and to route any leakage to a vapor recovery system or flare.

Optimal Fluid Compatibility

API Seal System Plan 76 & Plan 62 stands out for its compatibility with a wide array of flush media, including hydrocarbon liquids, inert gases, water, and specialty fluids. This versatility ensures reliable sealing in diverse process conditions, supporting industries such as refineries, chemical plants, and more. The systems non-contact design preserves fluid quality while efficiently managing process requirements.


Robust Instrumentation and Customization

These seal systems are engineered to accommodate pressure and vacuum gauges, and various instrumentation valves, enabling precise monitoring and control. Additionally, their customizable configurations allow adaptation to specific process connections, facilitating seamless integration into existing setups. Tailored options allow users to match the seal system with their exact operational needs.


Efficient Maintenance and High Durability

Designed with ease of access in mind, the API Seal System Plan 76 & Plan 62 simplifies inspection and servicing, minimizing downtime. The high-polish, corrosion-resistant finish enhances the systems durability and service life, ensuring dependable operation even in aggressive environments. Accessories like orifices, flow control valves, and drain fittings further extend system functionality.
